1996 SCMI Alfa 32C Panel Saw

126” X 126” Automated Clamp Panel Saw.

One owner, very well maintained and fully operational.

Max. Cutting Length                                                               126”

Max. Cutting Depth                                                                 126”

Max. Cutting Height                                                                 3-1/8”

Pusher speed Forward (FPM)                                                    118

Pusher speed Reverse (FPM)                                                   118

Rotation Speed of Main Blade                                                3800

Rotation speed of Scoring Blade                                              5800

Horsepower of Main Motor                                                      12

Horsepower of Scoring Motor                                                   2

Arbor Diameter of Main Blade                                                 80mm

Arbor Diameter of Scoring Blade                                             55mm

Fixed Bakelite Coated Front Air Floatation Table                  1500X500mm

Two Mobile Bakelite Coated Front Air Floatation Tables        1500X500mm

Variable Forward Speed (FPM)                                                20-195

Reverse Speed (FPM)                                                              195

Dust Hood Diameter                                                                 120mm

Weight (lbs.)                                                                              9,800

Electric and Dust Requirements: 55AMPS @ 230V, 2100 CFM
