Manufacturer’s Specifications
Maximum working width
25″
Maximum working thickness
8″ (16″, 20″, 24″ optional, please inquire)
Minimum working thickness
0.315″
Minimum workpiece length
12.2″
Bottom head motor
20 HP
Top planing head motor
25 HP
Feed motor
5 HP
Table elevation motor
1/2 HP
Cutterhead diameter
4″
Knife dimensions
30mm x 12mm x 1.5mm w/ bevels (96 pcs per head)
Cutterhead speed
5400 RPM
Feed speed (variable)
26-80 FPM
Dust ports
2 @ 6”
Table dimensions
27″ x 103″ (32″ from the floor)
Machine voltage
460/3/60 = 69.7 amps
575/3/60 = 56 amps
Machine dimensions (LxWxH)
105″ x 45.1″ x 67.7″
Net weight
6600 lbs
Packaging dimensions
109″ x 49″ x 74″
Gross weight
7700 lbs
