2013 Holz-her Streamer 1054 Edgebander

Location

Southeast USA

orCall 704-288-1904

Specifications

ManufacturerHolz-her
ModelStreamer 1054 Edgebander
Year2013
Stock Number009791

Description

- Overall length of machine 3,917mm

- Pull out workpiece support up to 600mm

- Feed speed 10 m/min

- Suits coils and edge strips 0.4 – 6 mm (depending on material)

- Work piece width minimum 65 mm

- Work piece length minimum 160 mm

- Work piece thickness 8 – 60 mm

- Pre-Milling Unit FG201 with 2 cutter units for jointing the panel edge.

- Edge feeder 1903, for automatic transport of coils and single strips with feed belt.

- Glue application system nozzle Glu Jet GJ301 (2.3kW, 50Hz) suitable for processing EVA and PUR adhesives. Heat up time only 3 minutes with patented nozzle technology.

- Pressure unit 1912-3, with first roller driven and two support pressure rollers.

- End trimming unit 1918 (60mm), twin saw, pneumatic adjustment for chamfer-type end trimming.

- Multifunctional trimming unit, FR201, for flush trimming, radius and chamfering.

- Finishing scraper unit 1929 with chip removers and 2 scraper carriers.

- Surface scraper unit 1964 for scraping off glue residue, including blow nozzles.
