2006 Weinig Powermat 500

Weinig Powermat 500 Moulder

MFG Specs:

460V; ELECTRONIC "SMART" BRAKES; POWERCOM+TOUCHSCREEN; MODEM

FEED ELECTRONIC 7.5HP;

#1:BOTTOM 10HP; 8000RPM; 1 13/16 SPINDLE; TABLE PLATES HARDENED B4

#2:RIGHT 15HP; 8000RPM; RAD ADJ;

#3:LEFT; 15HP; 8000RPM; PRESS SHOE W/2 LATERAL PRESS ROLLERS SPR MT

#4:TOP 25HP; 8000RPM; REC CB; TBL PLT FOR WOODEN INSERT; PROFILE GUIDE AFTER; PL

#5:BOTTOM 20HP; 8000RPM;

TABLES/FENCES CHROMED:INFEED TABLE 1050mm; 1 POWERED ROLLER ; MAN-WAX; CL LUBE

ELECTRICS:EL CAB + OPERATOR PEDESTAL SEPARATE

PRESSURE:FIXED PRESSURE ROLLERS ABOVE SPRING MTD; PRESSURE ROLLER AT INFEED

SAFETY: SAFETY INTERLOCK; 1 LIGHT INSIDE ENCL;

STRAIGHT EDGE;2 CLAMPING LENGTH 240 mm/ DIA 1 13/16";

GUIDE EDGE AFTER LEFT TOOL HOLDER;
